Experimental Study Of Wear Testing Of ASTM 440C Steel On A Ball-On-Disc Tribometer Using Variations Of Lubricants
Abstract
Bearings are important components in industry that function to reduce friction between moving parts for smoother and more efficient movement. However, friction that occurs can cause wear on the bearing surface. This study aims to analyze the wear volume, wear width, and wear rate of ASTM 440C steel material with variations of SAE 10W-30, SAE 10W-40, and SAE 140 lubricants at rotational speeds of 180 rpm, 270 rpm, and 310 rpm. Testing was carried out using a tribometer. ball-on-disc with a constant time of 10 minutes. The test results showed that the lowest wear width was obtained in SAE 10W-40 lubricant of 259.806 µm at 180 rpm, while the highest value of 417.894 µm also occurred in SAE 10W-40 at 270 rpm. The lowest wear volume was recorded in SAE 10W-40 of 0.0225 mm³ at 180 rpm, while the highest was 0.0942 mm³ at 270 rpm with the same lubricant. For the wear rate, the lowest value of 0.50 × 10⁻⁸ g/mm²·s was found in SAE 140 lubricant at 180 rpm, while the highest was 1.58 × 10⁻⁸ g/mm²·s occurred in SAE 10W-40 at 270 rpm. Overall, SAE 10W-40 lubricants are more suitable for use at low revs, while SAE 140 lubricants are recommended for high revs due to their greater viscosity and resistance to wear.
References
Alfian, D. G. C., Silitonga, D. J., Ramadhan, M. A. F., Ridhwan, I. N., Utomo, R. P., & Rudiarta, I. M. (2024). Comparative analysis of modular pin-fin heat sink performance: Influence of geometric variation on heat transfer characteristics. International Journal of Integrated Engineering, 16(6), 100–110. https://doi.org/10.30880/ijie.2024.16.06.010
ASTM International. (2020). ASTM G99-17: Standard test method for wear testing with a pin-on-disk apparatus. https://doi.org/10.1520/G0099-17
Berglund, K., Rodiouchkina, M., Hardell, J., Kalliorinne, K., & Johansson, J. (2021). A novel reciprocating tribometer for friction and wear measurements with high contact pressure and large area contact configurations. Lubricants, 9(12), 123. https://doi.org/10.3390/lubricants9120123
Boidi, G., Profito, F. J., Kadiric, A., Machado, I. F., & Dini, D. (2021). The use of powder metallurgy for promoting friction reduction under sliding-rolling lubricated conditions. Tribology International, 157, 106892. https://doi.org/10.1016/j.triboint.2021.106892
Cahyono, A. D., Prabowo, A. B., Burhanudin, A., & Ma’mun, H. (2022). Wear analysis of gray cast iron and aluminum Al₂O₃ with SAE 40 lubricant using pin on disc tribology test equipment. Quantum Teknika: Journal of Applied Mechanical Engineering, 3(2), 79–81.
Chipise, L., Jain, P. K., & Cornish, L. A. (2021). Sliding wear characteristics of WC–VC–Co alloys with various Ru additions. International Journal of Refractory Metals and Hard Materials, 95, 105429. https://doi.org/10.1016/j.ijrmhm.2020.105429
Farfan-Cabrera, L. I., Erdemir, A., Cao-Romero-Gallegos, J. A., Alam, I., & Lee, S. (2023). Electrification effects on dry and lubricated sliding wear of bearing steel interfaces. Wear, 516–517, 204592. https://doi.org/10.1016/j.wear.2022.204592
Frantoni Aji, A., Wahyu Prasetyo, T., Labib Firjatullah, A., Sufra, R., Pujiyulianto, E., Silitonga, D. J., Atro Auriyani, W., Yusupandi, F., & Gahana Cindi Alfian, D. (2024). Investigating the tribological performance of natural rubber additives in palm oil-based lubricants. ROTASI, 26(3), 57–64.
Kumar, S., & Kumar, R. (2023). Tribological characteristics of synthesized hybrid nanofluid composed of CuO and TiO₂ nanoparticle additives. Wear, 518–519, 204623. https://doi.org/10.1016/j.wear.2023.204623
Londa, P., dkk. (2023). The effect of lubricating oil type on wear rate in contact between two types of material. Journal of Mechanical Engineering, 18(3), 363.
Lu-Minh, C., Njiwa, P., Leclerc, K., Chen, Y. M., Delgado, J., & Cardey, P. F. (2022). Effectiveness of greases to prevent fretting wear of thrust ball bearings according to ASTM D4170 standard. Results in Engineering, 14, 100468. https://doi.org/10.1016/j.rineng.2022.100468
Michelberger, B., Jaitner, D., Hagel, A., Striemann, P., Kröger, B., Leson, A., & Lasagni, A. F. (2021). Combined measurement and simulation of piston ring cylinder liner contacts with a reciprocating long-stroke tribometer. Tribology International, 163, 107146. https://doi.org/10.1016/j.triboint.2021.107146
Nassef, B. G., Pape, F., Poll, G., Schenzel, J., Bergmann, B., & Denkena, B. (2024). Evaluating the tribological behaviour in cutting operations using a modified ball-on-disc open tribotester. Lubricants, 12(3), 77. https://doi.org/10.3390/lubricants12030077
Prabowo, A. (2022). Wear analysis of gray cast iron using pin-on-disc tribometer with load variations of 0.5 kg and 0.7 kg with SAE 40 lubricant [Skripsi]. Universitas PGRI Semarang.
Rahman, A. (2012). Experimental study and analysis of wear rate of alternative materials on locomotive brake shoes. Jurnal/Proceeding, 5(2).
Reeves, C. J., Kasar, A. K., & Menezes, P. L. (2021). Tribological performance of environmentally friendly ionic liquids for high-temperature applications. Journal of Cleaner Production, 279, 123666. https://doi.org/10.1016/j.jclepro.2020.123666
Roziqin, I. N. (2023). Analysis of the effect of lubricant variations on ST 60 steel wear using a pin-on-disc tribometer. Quantum Teknika: Journal of Applied Mechanical Engineering, 4(2), 102–106.
Surawan, T., & Mulyadi, D. (2019). The effect of loading time and speed on the wear of copper (Cu) and carbon (C) alloys. Journal of Technology, 6(2), 71–84.
Sutriyani, Y. (2018). Measurement of kinetic friction coefficient of green beans (Phaseolus radiatus, Linn) against various metal plate materials using the video-tracking method. Naskah ilmiah.
Syafa’at, I., Muchammad, M., Zidni, M. I., & Darmanto, D. (2021). The effect of using SAE 40 lubricant on the wear of FCD cast iron pins in pin-on-disc tribotester testing with load variations. Cendekia Eksakta, 6(1), 42–48.
TS, O. Y., Darmanto, D., & Syafa’at, I. (2020). Wear analysis of ST 70 steel cylinder using SAE 140 lubricated pin-on-disc tribotester and load variations. Momentum Scientific Journal, 16(1).
Vladescu, S. C., Lumby, R., Gant, A., Dyer, H., & Reddyhoff, T. (2025). Using lubricant composition to control friction-induced vibration in an elastomer–steel contact representing a hydraulic seal. Tribology International, 202, 110346. https://doi.org/10.1016/j.triboint.2024.110346
Vrček, A., Hultqvist, T., Johannesson, T., Marklund, P., & Larsson, R. (2020). Micro-pitting and wear characterization for different rolling bearing steels: Effect of hardness and heat treatments. Wear, 458–459, 203404. https://doi.org/10.1016/j.wear.2020.203404
Wahid, University, & Hasyim Semarang. (2013). Faculty of Engineering, Wahid Hasyim University, Semarang 31. Jurnal, 9(2), 31–33.
Witoyo, W. A. (2021). Wear test of hardchrome-coated cast iron using pin-on-disc tribotester. MOMENTUM Scientific Journal, 17(2), 144.
Yulianda, A., Maksum, H., & Fernandez, D. (2015). The effect of using various lubricant brands on engine heat levels in four-stroke motorcycles. Automotive Engineering Education Journals, 3(1).
Szpunar, M., Trzepieciński, T., Żaba, K., Ostrowski, R., & Zwolak, M. (2021). Effect of lubricant type on the friction behaviours and surface topography in metal forming of Ti-6Al-4V titanium alloy sheets. Materials, 14(13), 3721. https://doi.org/10.3390/ma14133721
