Effect of Rice Husk Ash and Clay Powder as Cooling Media in Post Weld Heat Treatment (PWHT) on The Impact Toughness of SMAW-Welded SS400 Steel

Angga Hermawansyah; Zainal Abadi; Delima Yanti Sari; Rifelino

doi:10.24036/f6gkaq38

Authors

Angga Hermawansyah Universitas Negeri Padang
Zainal Abadi Universitas Negeri Padang
Delima Yanti Sari Universitas Negeri Padang
Rifelino Universitas Negeri Padang

DOI:

https://doi.org/10.24036/f6gkaq38

Keywords:

PWHT, SS400, Cooling Media, Impact Toughness, SMAW

Abstract

This study investigates the effect of variations in cooling media during Post Weld Heat Treatment (PWHT) on the impact toughness of low carbon steel SS400. The main problem addressed in this research is how differences in cooling medium characteristics influence the cooling rate, which subsequently affects the impact toughness of welded material. The objective of this study is to determine the effect of using rice husk ash, clay, and air as cooling media on the impact toughness value of SS400 steel. The experimental method was employed by applying PWHT to SMAW-welded specimens, followed by Charpy impact testing to obtain the final deflection angle, which was then converted into impact energy and impact value (HI). The results show that clay cooling medium provides the highest average impact toughness value of 1.175 J/mm², followed by rice husk ash at 1.107 J/mm², while air cooling yields the lowest value of 0.845 J/mm². These differences indicate that the thermal characteristics of the cooling media significantly influence the material’s ability to absorb energy before fracture, which is related to the stability of the cooling rate during the PWHT process. It can be concluded that variations in cooling media affect the impact toughness of SS400 steel, where more stable cooling conditions lead to higher toughness values.

References

Arrochman, A. F., & Rasyid, A. H. A. (2024). Pengaruh Variasi Media Pendingin Setelah PWHT Pengelasan SMAW Baja ST37 Terhadap Ketangguhan Dan Struktur Mikro. Jtm, 13(02), 75–82. https://doi.org/10.26740/jtm.v13n02.p75-82

Azis, R. A., & Saputro, H. (2019). Pengaruh Variasi Diameter Elektroda E7018 Terhadap Kekuatan Tarik , Kekerasan , dan Struktur Mikro Pengelasan pada Baja Karbon Rendah Jenis SS400 dengan Metode SMAW. JURNAL TEKNIK, 17(2), 94–105.

Jeffus, L. (2012). Welding and Metal Fabrication. Delmar.

Jiang, W., Luo, Y., Zeng, Q., Wang, J., & Tu, S. T. (2021). Residual stresses evolution during strip clad welding, post welding heat treatment and repair welding for a large pressure vessel. International Journal of Pressure Vessels and Piping, 189, 104259. https://doi.org/10.1016/j.ijpvp.2020.104259

Kalyankar, V. D., & Chudasama, G. (2018). Effect of post weld heat treatment on mechanical properties of pressure vessel steels. Materials Today: Proceedings, 5(11), 24675–24684. https://doi.org/10.1016/j.matpr.2018.10.265

Kusminah, I. L., Anggara, D., Wardani, D., Widodo, E. W. R., Nafi, M., Handoko, L., Djati, A. L., & Trianto, R. A. (2024). Analysis of the Effect of PWHT on the Corrosion Test of API 5L X65 Material in Submerged Arc Welding. Journal of Mechanical Engineering, Science, and Innovation, 4(2), 122–132. https://doi.org/10.31284/j.jmesi.2024.v4i2.6556

Lancaster, J. F. (1980). Metallurgy of Welding Third Edition (3rd ed.). Allen & Unwin.

Mansjur, Z., & Suharto, M. F. (2024). Pengaruh Media Pendingin Post–Weld Heat Treatment (PWHT) Terhadap Karakteristik Mekanik dan Struktur Mikro Baja Karbon Hasil Pengelasan Shielded Metal Arc Welding (SMAW). Jurnal Mesin Nusantara, 7(1), 126–137. https://doi.org/10.29407/jmn.v7i1.22434

Nasra, K. A., Zuldesmi, & Kewas, J. C. (2020). Pengaruh Post Weld Heat Treatment Terhadap Sifat Mekanik dan Struktur Mikro Baja Karbon ST42 dengan Pengelasa SMAW (Shielded Metal Arc Welding). ACTUATOR: Jurnal Teknik …, 1(1), 26–36.

Ramadhani, S., Basyirun, B., Rusiyanto, R., & Sunyoto, S. (2022). Pengaruh Variasi Temperatur Preheat Pada Pengelasan Smaw Terhadap Struktur Mikro Dan Kekerasan Baja Karbon SS400. Jurnal Dinamika Vokasional Teknik Mesin, 7(1), 12–20. https://doi.org/10.21831/dinamika.v7i1.46929

Roslan, N. S., Hadzir, M. M., Ismail, I. F., Mat, M. N. H., & Yusup, E. M. (2024). A Review on The Effect of Post-Weld Heat Treatment (PWHT) on Its Thermal Analysis and Mechanical Properties of Welded Metallic Pipe. International Journal of Integrated Engineering, 16(2), 296–313. https://doi.org/10.30880/ijie.2024.16.02.031

Saragi, J. F. H., Bahri Pratama, A., Boangmanalu, E. P. D., Qadry, A., & Sinaga, F. T. H. (2023). Pengaruh Temperatur terhadap Kekuatan Impak pada Material Besi Nako 10 mm. Jurnal Mesil (Mesin Elektro Sipil), 04(01), 45–51. https://ceredindonesia.or.id/index.php/mesil

Song, T., Wang, Z., Bao, Y., Gu, C., & Zhang, Z. (2024). Effect of Silicon–Manganese Deoxidation on Oxygen Content and Inclusions in Molten Steel. Processes, 12(4). https://doi.org/10.3390/pr12040767

Wahyunanta, C., & Drastiawati, N. S. (2023). Pengaruh Variasi Media dalam Proses PWHT Pengelasan SMAW untuk Material Baja SS400 terhadap Nilai Kekerasan dan Kekuatan Tarik. Jurnal Teknik Mesin, 11(1), 13–18.
